Brief Introduction

With ever growing and fast technological changes taking place in construction of buildings, concept of making buildings is fast changing from conventional labour intensive progress to pre-fabricated and modular concept in making of buildings which are less time consuming and are environment friendly including better resistance towards frequent earthquakes.

Conventional RCC Chajjas are less durable, prone to cracks and difficult to maintain hence need to have durable and prefabricated chajjas which are light in weight and ease to install and maintain over its long period of use.

Why FRP Chajja?

FRP is a wonder composite material and is generally known for its very high strength, durability, resistance to high temperature and extremes of weathering, resistance to environmental corrossion and being light in weight, hence due to above inherent properties FRP prefabricated chajjas in one single piece are the most prefered and suitable material for the said application.

Ease of Installation

Prefabricated FRP Chajja in one single piece are light in weight hence easy to lift and fix at suitable height with minimum arrangements at site. Below details for installation will further define the ease of handling and installation of FRP Chajja at site.

Product Specification

Providing & fixing of factory made Fiberglass Reinforced Plastics (FRP) “CHAJJA”- 4mm thick of “Roofclad” brand or equivalent in required colour, size and design made by Resin Transfer Moulding (RTM) Machine Technology, resulting in void free compact laminate in single piece, having smooth gradual slope curvature for easy drainage of water and duly reinforced by 2 nos. vertically and 1 nos. horizontally 50x2mm thick M.S. Flat with 12mm in built hole for grouting on the existing wall along with the 50mm flanges duly inserted and sealed in the wall complete in one single piece casted monolithically including all necessary fittings. The FRP Chajja should be manufactured using unsaturated Polyester resin as per IS: 6746 duly reinforced with fiberglass chopped strand mat (CSM) as per IS: 11551 complete with protective Gelcoat U/V coating on Top for complete resistance from the extreme of temperature, weather & sunlight.

Applications

External protection to all windows, doors, openings, etc. in any housing, commercial, warehouses, residential buildings.
