UPVC Profile Door

30 mm thick Polyvinyl Chloride (PVC) Door Shutter made of styles and rails of a UPVC hollow section of size 60 x 30 mm and wall thickness 2 mm - 0.2 mm with inbuilt decorative moulding edging on one side. The styles and rails mitred and joined at the corners by means of M.S. galvanized plastic brackets of size 75 x 220 mm having wall thickness 1.0 mm and stainless steel screws. The styles of shutter reinforced by inserting galvanized M.S. tube of size 25 x 20mm and 1mm ± 0.1 mm wall thickness. The lock rail made up of “H” section, a UPVC hollow section of size 100 x 30mm and 2 mm ± 0.2 mm wall thickness fixed to the shutter styles by means of plastic/ galvanized M.S. “U” cleats. The shutter frame filled with a UPVC Multi Chambered single panel of size not less than 620 mm, having over all thickness of 20 mm and 1 mm ± 0.1 mm wall thickness. The panel filled vertically and tie bar at two places by inserting horizontally 6mm galvanized M.S. rod and fastened with nuts and washers.

UPVC Door

24mm thick PVC Door shutters made of styles and rails of a hollow section of size 59 x 24 mm and wall thickness 2mm ± 0.2mm with inbuilt edging on both sides. The styles and rails mitred and joined at the corners by means of M.S. galvanized/ plastic brackets of size 75 x 220 mm having wall thickness 1.0 mm and stainless steel screws. The styles of the shutter reinforced by inserting galvanized M.S. tube of size 20x20 mm and 1mm to ±0.1mm wall thickness. The lock rail made up of ‘H’ section, a UPVC hollow section of size 100x24mm and 2mm ± 0.2mm wall thickness fixed to the shutter styles by means of plastic/ galvanized M.S. ‘U’ Cleats. The Shutter frame filled with a UPVC multi- chambered single panel of size not less than 620mm, having over all thickness of 20mm and 1mm±0.1 mm wall thickness. The panel filled vertically and tie bar at two places by inserting horizontally 6mm galvanized M.S. rod and fastened with nuts and washers.

UPVC Profile Frame

UPVC Door Frame made of UPVC extruded section having an overall dimension as below (tolerance ±1mm) with wall thickness 2.0 mm ± 0.2 mm, corners of the door frame to be mitred and welded of plastic, galvanized brackets and stainless steel screws. The hinge side vertical of the frames reinforced by galvanized M.S. tube of size 19 x 19 mm and 1 mm ± 0.1 mm wall thickness and 3 nos. stainless steel hinges fixed to frame.

1.Extruded section profile size 48 x 40 mm
2.Extruded section profile size 42 x 50 mm
